Aerospace Gasket Parts Vacuum Casting
  • Aerospace Gasket Parts Vacuum Casting - 0 Aerospace Gasket Parts Vacuum Casting - 0

Aerospace Gasket Parts Vacuum Casting

Vacuum Casting may be used with a multitude of materials. This method of casting is typically made polyurethane prototype parts in a timely manner. A wide variety of textures, rigidity, strength, hardness or softness may be produced with this manufacturing technique. The parts are usually made with polyurethane resins because it can emulate the texture of other materials. The molds are typically made out of silicone and may even be produced with a 3D printer.The following is about Aerospace Gasket Parts Vacuum Casting.

Send Inquiry

Product Description

Aerospace Gasket Parts Vacuum Casting


Vacuum Casting may be used with a multitude of materials. This method of casting is typically made polyurethane prototype parts in a timely manner. A wide variety of textures, rigidity, strength, hardness or softness may be produced with this manufacturing technique. The parts are usually made with polyurethane resins because it can emulate the texture of other materials. The molds are typically made out of silicone and may even be produced with a 3D printer.


A mold is placed within a vacuum chamber. The material needs to be degassed prior to placing within the mold. The vacuum then is activated, making an airtight object that is very precise to the design of the mold. Immediately after, the item is then cured in a high heat oven prior to the removal of the mold. The mold is then reused if they are not cracked in the curing process.


It is a good way to enhance our products and solutions and repair. Our mission will be to build creative solutions to consumers with a great experience for High reputation China Aerospace Gasket Parts Vacuum Casting, Initial enterprise, we understand each other. Additional enterprise, the trust is getting there. Our firm usually at your service anytime. High reputation China Zinc Die Casting, Die Casting Part, Our mission is to deliver consistently superior value to our customers and their clients. This commitment permeates everything we do, driving us to continuously develop and improve our products and the processes to fulfill your needs.

1.Product Parameterfor Aerospace Gasket Parts Vacuum Casting


Standard lead time

Up to 10 copies within 15 working days

Standard accuracy

±0.3% (with lower limit on ±0.3 mm on dimensions smaller than 100 mm)

Minimum wall thickness

To ensure that the mold is filled properly, a wall thickness of at least 0.75 mm is necessary. For best results, we recommend a wall thickness of at least 1.5 mm

Maximum part dimensions

The size of the mold is limited by the dimensions of the vacuum chamber (1900 x 900 x 750 mm) and by the volume of the product (maximum volume: 10 liters)

Typical quantities

Up to 25 copies per mold (depending on the mold’s complexity and the casting materials)

Surface structure

High-quality surface finish comparable to injection molding


2.Product Feature for  Aerospace Gasket Parts Vacuum Casting


Manufacturing Services

3D SLA printing (master patterns); CNC machining; laser cutting and etching; vacuum casting with overmolding; silk screening and pad printing; polishing; painting

Materials

Heicast 8263, Al-5052, UPX-8400, PMMA, PX-5210, AL-6061, Somos 14120

Quantities

20 Sets


3.Product Details for Aerospace Gasket Parts Vacuum Casting


Vacuum Casting Technology is far more advanced in product development, also the unique guides make it attractively and increasingly developing in China.

At Shbury, we can provide you a full solution for vacuum casting and silicone molding. We have a range of machines, including from manual to high capacity computer automated for the economic production of short run, end-use parts, and prototypes - up to at least 50 parts from a single mold.


4.FAQ


Q1:Where can I get product&price information?

A1:Send us inquirye-mail, we will contact you as we receive your mail.

Q2:How long can i get the sample?

A2:Depends on your specific items,within 3-7 days is required generally.

Q3:What's kinds of information you need for quote?

A3:Kindly please provide the product drawing in PDF,and will be better you can provde in STEP or IGS, send the parts materials, quantity, surface finishing and other requirements to us as well.

Q4: what's the payment terms?

A4: We accept 50% as payment deposit, when the goods is done, we take photoes for your check and you then pay the balance.

For small amount, we also accept Paypal, Paypal commission will be added to the order. For big amount, T/T is preferred

Q5.Are you a trading company or factory?

A6:We are direct factory with 10 experienced engineers and more than 30 employees as well approximate 3,000 square meters workshop area.

Q6. What shall we do if we do not have drawings?

Please send your sample to our factory,then we can copy or provide you better solutions. Please send us pictures or drafts with dimensions(Length,Hight,Width),CAD or 3D file will be made for you if placed order.

Q7. Can we get some samples before mass production?

A8:Absolutely

Q8. What is your MOQ?

Our MOQ is 1pcs, it is also our one of advantage, even you have less budget, or want to reduce the risks before production, we both can accept the less MOQ.

Q9: Will you do 100% inspection or random inspection ?

We will do 100% inspection for samples, random inspection for mass production. When manufacturing, we will control the dimensions , do PQC in mass production.

Q10. How to do if the parts not match with drawings we received?

Contact us immediately, send the pictures and tell us the issues, we will check and repair or re-make the goods with free.

Q11. You will how to ship the parts to me?

When products finished, also passed by our QC, we will ship out the parts to you by DHL, Fedex , or by sea after communication


6.Deliver,Shipping forAerospace Gasket Parts Vacuum Casting
